High Speed Cylindrical Digital Inkjet UV Printer with 3 pcs Epson 1600 Printhead

Name: High Speed Cylindrical Digital Inkjet UV Printer with 3 pcs Epson 1600 Printhead
SKU: SIT-RC-HSC
Price: 118655784 COP
Availability: InStock

Precio unitario

COP 118.655.784

/set

Descuentos por volumen

Cantidad

Descuento

Precio por unidad

COP 118.655.784

COP 115.238.244

COP 111.820.704

10%

COP 107.263.984

Costo total

COP 118.655.784

Cantidad

/set

Detalles del producto

Descripción

High Speed Cylindrical Digital Inkjet UV Printer with 3 pcs Epson 1600 Printhead

Features:

The maximum printable drop is 1.5cm.

Intelligent angle adjustment device to achieve cone-shaped printing.

360 ° seamless splicing solves the problem of difficult seams.

The equipment comes with an automatic cleaning and maintenance module for easier maintenance.

The white colored oil is used together, resulting in exquisite and delicate effects.

The relief is three-dimensional and the color is firm and not easy to fall off.

Specification:

Print head		Epson 1600*3pcs standard
Print length		80-280mm
Cylinder/cone printing diameter range		Φ40-120mm
Number of printhead		3pcs
Ejection frequency		Single highest 50khz
Droplet volume		3.5pl
Taper printing range		<5°
Print version		White and color and varnish print at same time
Print mode		CMYK+W+V
Resolution		720*1200dpi
Printer dimension LWH		1320mm720mm1620mm
G.W.		380KG
Rip software		RIIN
Print speed range		40s-3min/pcs
Graphic format		Tiff,Jpg,Eps,Pdf,Png,AI
Connection method		Network cable
Power		AC220V, 50HZ
Rated power		3500W
Working environment	Temperature	20°C-28°C
	Humidity	35%-65%
Operating conditions	Dust	Avoid dustyenvironments
	Illumination	Avoid direct sunlight
Ink type		Environmental UV curing ink
Taper electric adjustment function		Yes
Height measurement function (imodeling of special-shaped products)		Optional
Carriage and print head anti-collision		Intelligent anti-collision oflaser aiming
Printing material sensor		Optical fiber amplifier
UV curing method		Water cooling

Diverse effects:

The software can set various modes and is simple and easy to understand. Increasing the amount ofink can make the relief effect more obvious, the partial gloss effect to highlight the layering, and the full-width gloss effect to be scratch-resistant and wear-resistant.

The software adds a seamless splicing algorithm, which allows you to easily achieve a seamless splicing effect after setting the size. lt is easy to operate and the effect is stunning.

Supports a variety of printing materials, such as frosted/smooth paint, stainless steel metal, plastic, bamboo, ceramics, wood, etc., with running water UV lamp control technology, segmented temperature control, and adhesion is fully guaranteed.

Application:
