UV One Pass Digital Printer with 90°/0° Printing
3-head
Unit cost
COP 167,948,241
/set
Wholesale discounts
Quantity
Discount
Price per unit
1
0%
COP 167,948,241
Options
Por Favor Eliga el Tipo Por Favor Eliga el Tipo
Total Cost
COP 167,948,241
Amount
/set
1
Side-Flat All-in-One UV One Pass Digital Printer with Toshiba CF3 Industrial Printhead
- High-precision color reproduction
- Front and side double-sided printing
- Plasma surface treatment
- High-speed plateless printing
- Heightened printing: 1.5 cm
- High-power UV curing
Specification:
| Printehead | Toshiba industrial printhead |
| Printing accuracy | 300/600 dpi |
| Number of colors supported by a single nozzle | 2 colors |
| Single nozzle width | 0-54mm |
| Printing speed | 0-30m/min |
| Inkjet technology | micropiezoelectric technology |
| Ink supply | Negative pressure circulating ink supply |
| Ink type | UV eco-friendly ink |
| Color Settings | C M Y K + W +V(Optional) |
| Feed width | 0-240mm |
| Shipping method | Automatic/Manual Feeding (Optional) |
| Print media thickness | 0-130mm (Optional) |
| Drive system | Servo Motor Drive |
| Voltage | 220VAC 50Hz |
| Maximum Power | 6000W |
| Environmental Requirements | Temperature 10℃~35℃, Relative Humidity 20%~80%, No Condensation |
| Operating Noise | 60-80 db |
| Operating System | Win7/Win10/Win11 |
| Data Interface | Ethernet |
| Data transmission | USB3.0 (compatible USB2.0) |
| Frame structure | Steel frame structure Broussonetia papyrifera Longmen |
| Picture format | PDF/TIFF/JPG |
| Printing material | Plastic cups, plastic bowls, food containers, biodegradable food containers, stainless steel cups/glass cups, and other materials such as PP, PE, PC, etc. |
| Printer size | L 138cm * W 122cm * H 120cm |
| Net weight of printer | 177.8 KG |
| Packaging method | Solid wooden crate packaging |
| Wooden Case Dimensions | L 155cm * W 135cm * H 185cm |
| Gross Weight | 278 KG |
