B4-1013/1815/2516/3020 Large Format Flatbed Digital Cutting Machine with Rolling Platform
R1815
Unit cost
COP 98,560,619
/set
Wholesale discounts
Quantity
Discount
Price per unit
1
0%
COP 98,560,619
Options
Por Favor Eliga el Tipo Por Favor Eliga el Tipo
Total Cost
COP 98,560,619
Amount
/set
1
R means Rolling platform
Specifications:
| Model | B4-1013 | B4-1815 | B4-2516 | B4-3020 |
| Effective cutting area(MM) | 1000x1300 | 1800x1500 | 2500x1600 | 3000x2000 |
| Overall dimension(MM) | 1490*1585*870 | 2740*1885*870 | 3440*1985*870 | 3940*2385*870 |
| Specical size | Customizable | |||
| Safe device | Physical anti-collision mechanism + infrared induction anti-collision to ensure production safety | |||
| Tools | Electric oscillating tool，Universal cut tool，Kiss cut tool，CCD，Cursor，Pen Pneumatic oscillating tool，Power rotary tool，Creasing tool,VCUT，Universal router tool |
|||
| Cutting thickness | ≤40mm(up to 55mm for optional) | |||
| Cutting speed | ≤1200mm/s | |||
| Cutting precision | ≤0.1mm | |||
| Repeated accuracy | ≤0.05mm | |||
| Fixing method | vacuum suction | |||
| lnterface | Ethernet port | |||
| Ethernet port | lntelligent digital control servo system | |||
| Command | DXF，HPGL，PDF，PLT compatible format | |||
| Control panel | Multi-language LCD touch panel | |||
| Suction power | 3KW | 7.5KW | 7.5KW | 11KW |
| Power Supply | AC220/380V 50~6OHz | |||
| Working Environment | Temperature: -10℃~40℃,Humidity : 20%~80%RH | |||
| Upgradeable Configuration | vacuum pump with frequency transformer vacuum pump silencing box Aluminnum vaccum table with 8 air zones Rack transmission Supply |
|||
Detalles:
| Standard | CCD system, A:Oscillating knife, B:universal cut tool （C:Kiss cut/D:V-cut/E:Creasing wheel , Choose one of three） |
| Optional |
F:Pneumatic oscillating tool add $2000
G:Universal router tool add $5200 H:Electric oscillating tool add $2600 I:Power rotary tool add $2000 |
 |
Herramienta de Corte Osciladora |
|
 |
Herramienta V-CUT |  |
 |
Cuchillo de arrastre |
|
 |
Herramienta Kiss-Cut |  |
 |
Ruedas de pliege |  |
 |
Sistema CCD |  |
 |
Herramienta de fresado |  |
Application:
