Full Color Indoor P3 LED Display Screen
Specification
| Parameter | Value | |
|
Physical
|
Pixel Configuration | SMD2020 full black frame (Common configuration) |
| Pixel Pitch(mm) | 3 | |
|
Pixel matrix per panel module |
64x64 | |
|
Pixel density(pixels/sq.m.) |
111111 | |
|
Module Dimensions (LxWxH)/(mm) |
192x192 | |
| Ribbon cable type | 16Px2 | |
|
Electronic |
Driving Type | 1/16 |
|
Optical |
Brightness(nit) | 1200 |
|
Optimal Horizontal Viewing Angle(°) |
120 | |
|
Optimal Vertical Viewing Angle(°) |
120 | |
|
Electrical
|
Input Voltage(V) | DC5V |
|
Module Input Power Typical Value ( W / sq.m ) |
480 | |
|
Module Input Power Maximum Value (W/sq.m) |
1200 | |
|
Circumstance |
Storage Temperature(℃) | ―30 - 60 |
| Operating Temperature(℃) | ―20 - 50 | |
| Storage Humidity(RH) | 10%~90% | |
| Operating Humidity(RH) | 10%~90% | |
| Lifetime Typical Value(hrs) | 100000 | |
Module mounting holes bitmap
Remark: all the size of the unit for mm; Shape tolerance to 0, 0.1, pore size tolerance of + / - 0.05.
