AD150 Automatic Rounding Bending Machine
单件价格
COP 47,045,058
/件
批量折扣
数量
折扣
单价
1
0%
COP 47,045,058
总费用
COP 47,045,058
数量
/件
1
春节快乐！
我们将在 2 月 1 日至 8 日期间休假，并将于2 月 9 日恢复办公。
AD150 Automatic Rounding Bending Machine
单件价格
COP 47,045,058
/件
批量折扣
数量
折扣
单价
1
0%
COP 47,045,058
总费用
COP 47,045,058
数量
/件
1
| Model | AD150 |
| Feed Speed | 150mm/s |
| Feed Accuracy | ±0.2mm |
| Bend Axis Torque | 400N·M |
| Die Axis Length | 120mm |
| Min Bend radius | 50mm |
| Control System | Autodrive Automatic Bending System |
| Machine Size | L1100mm*W700mm*H1150mm |
| L1250mm*W840mm*H1270mm | |
| Machine Watt | 2.3KW |
| Voltage | 220VAC |
| Gross Weight | 400Kg |
| Shape | Circle、ellipse、runway circle、polygon and irregular figure |
| Material | Aluminum profile、Stainless steel |
| Industry Application | Frame、mirror frame、Decorative picture、Ceiling、lamps and lanterns、Advertising、Furniture and metal forming industry |
Details:
 |
Feed Structure Feeding axis is made of four sets nylon. Gear drivers Rolling continuous feeding structure，fast speed，for example, if we process a 300mm circle, it just spend 9.84 second. |
| Material Home Functional Special design for material detector switch, when material is not enough longer, software will remind you to add new material. |
 |
 |
Bend Structure |
| Machine Frame |
 |
 |
One-button start function Update the operational procedure, Touch - tone control pattern, when we need to change the dies of aluminum profile, we can save time, more safety, more convenient. |
| Software More humanize control software, more easy to operate, one machine will help you to build assembly line，more higher productivity, easy to change the data when you use different material, no need to test again. |
 |
Semi-finished Product:
Sample Show:
